Home > Products > 4-inch 24v diameter 105mm tire width 42 opening 62 double-sided threaded shaft PU water guide groove model-Hall sensor
4-inch-diameter-105mm-tire-width-42-open-62-bilateral-threaded-shaft-PU-water-guide-tank-model-6.png
4-inch-diameter-105mm-tire-width-42-open-62-bilateral-threaded-shaft-PU-water-guide-tank-model-1.jpg
4-inch-diameter-105mm-tire-width-42-open-62-bilateral-threaded-shaft-PU-water-guide-tank-model-2.jpg
4-inch-diameter-105mm-tire-width-42-open-62-bilateral-threaded-shaft-PU-water-guide-tank-model-3.jpg
4-inch-diameter-105mm-tire-width-42-open-62-bilateral-threaded-shaft-PU-water-guide-tank-model-4.jpg
4-inch-diameter-105mm-tire-width-42-open-62-bilateral-threaded-shaft-PU-water-guide-tank-model-6.jpg

retail price:
$
Wholesale Price:
To be discussed
Customized price:
To be discussed
Custom made:
Tire
Fixed axis method
Wirewound resistor
Connectors
Wheels

Recommended Products

Product Introduction

The 24V rated voltage is compatible with commercial and industrial power supplies. Customizable widths of 105mm diameter x 42mm are available, along with PU water-conducting tires for enhanced slip resistance and wear resistance. A 62mm clearance and double-sided threaded shaft support standardized assembly, eliminating the need for secondary machining. Built-in Hall effect sensors provide high-precision speed and position feedback, making it suitable for applications such as warehousing, logistics, and industrial flatbed trucks. Customizable bulk purchases are available, meeting manufacturers' requirements for stable drive and precise speed control.
Product Introduction
Installation Instructions
1. Connect the motor to the controller and power supply according to the wiring diagram on the controller.
2. The tire is installed outside the outer rotor hub.
3. When the power cord passes through metal parts, it should be protected by non-metal products.
4. Special attention: When the motor is powered on by the driver and the motor does not move or freezes, or it heats up abnormally quickly, the power must be turned off and on within three seconds to adjust the electrical angle or drive output to avoid motor failure

Product Parameters

The main parameters

Number Projects Specification Remarks
1 Motor diameter 105mm (slight deviation including tire size) Subject to actual product
2 Rated voltage 24V
3 Rated power 250W
4 Rated rotating speed 1800±50rpm
5 Rated current 6±0.5A
6 Theoretical torque 4.8 N/M
7 Degree of phases 120°
8 Number of poles 20 poles
9 Out of the shaft Double-sided threaded shaft (mm)
10 Lead exposed 500mm
11 Size of connectors 3+6 waterproof connector
12 Brake mode Electromagnetic brake
13 Shaft material 45cr (alloy steel)
14 Waterproof rating IP55
15 Maximum load 100kg
16 Environmental requirements -20℃ to 65℃
